Mycenter-3020G, 15k "Sparkchanger"
Specifications
- Table Size:19.7” x 33.9” (500 x 860mm)
- Travel (X, Y, Z):30” x 20.1” x 20.1”(762 x 510 x 510mm)
- Spindle Taper:NST No. 40
- Spindle Speed:40~15,000rpm
- Tool Storage Capacity:30Pcs.
- Tool Change Time (T-T/C-C):2.2 Sec. /4.4 Sec.
- Rapid Feed (X, Y, Z):1,969ipm (50m/min) X/Y x 1,417ipm (36m/min) Z
- Power Requirement:30KVA
Features
- 180 degree 2-Station rotating pallet changer for high production requirements
- Ideal for heavy duty cutting of molds to the high-speed accuracy cutting for high precision parts
- Positioning Accuracy: ±0.000078” Full Stroke, Repeatability: ±0.000039”
- Rigid Meehanite cast iron construction with solid box ways (X & Y Axes)
- Versatile 30HP AC, 15,000rpm direct drive, dual contact spindle
- Flexibility with the ability to add 4th/5th axis in the field
- 2,800 block/sec processing speeds for smoother and faster machining of complex work pieces
Mycenter-3020G, 15k
Specifications
- Table Size:19.7” x 33.9” (500 x 860mm)
- Travel (X, Y, Z):30” x 20.1” x 20.1”(762 x 510 x 510mm)
- Spindle Taper:NST No. 40
- Spindle Speed:40~15,000rpm
- Tool Storage Capacity:30Pcs.
- Tool Change Time (T-T/C-C):2.2 Sec. /4.4 Sec.
- Rapid Feed (X, Y, Z):1,969ipm (50m/min) X/Y x 1,417ipm (36m/min) Z
- Power Requirement:30KVA
Features
- Enhanced control capability with Kitamura’s feature packed Arumatik-Mi control
- Ideal for heavy duty cutting of molds to the high-speed accuracy cutting for high precision parts
- Positioning Accuracy: ±0.000078” Full Stroke, Repeatability: ±0.000039”
- Rigid Meehanite cast iron construction with solid box ways (X & Y Axes)
- Versatile 30HP AC, 15,000rpm direct drive, dual contact spindle
- Plumbed and ready for coolant thru the spindle – can be added in field
- 2,800 block/sec processing speeds for smoother and faster machining of complex work pieces
- Flexibility with the ability to add 4th/5th axis in the field
Mycenter-3020G, 20k “Sparkchanger”
Specifications
- Table Size:19.7” x 33.9” (500 x 860mm)
- Travel (X, Y, Z):30” x 20.1” x 20.1” (762 x 510 x 510mm)
- Spindle Taper:NST No. 40
- Spindle Speed:20~20,000rpm, Gear Drive, 4-Step
- Tool Storage Capacity:30Pcs.
- Tool Change Time (T-T/C-C):2.2 Sec. /4.4 Sec.
- Rapid Feed (X, Y, Z):1,969ipm (50m/min) X/Y x 1,417ipm (36m/min) Z
- Power Requirement:30KVA
Features
- Enhanced control capability with Kitamura’s feature packed Arumatik-Mi control
- Ideal for heavy duty cutting of molds to the high-speed accuracy cutting for high precision parts
- Positioning Accuracy: ±0.000078” Full Stroke, Repeatability: ±0.000039”
- Rigid Meehanite cast iron construction with solid box ways (X & Y Axes)
- High Torque 20HP AC, 20,000rpm 4-step gear driven, dual contact spindle
- Plumbed and ready for coolant thru the spindle – can be added in field
- 2,800 block/sec processing speeds for smoother and faster machining of complex work pieces
- Flexibility with the ability to add 4th/5th axis in the field
Mycenter-3020G, 20k
Specifications
- Table Size:19.7” x 33.9” (500 x 860mm)
- Travel (X, Y, Z):30” x 20.1” x 20.1”(762 x 510 x 510mm)
- Spindle Taper:NST No. 40
- Spindle Speed:20~20,000rpm, Gear Drive, 4-Step
- Tool Storage Capacity:30Pcs.
- Tool Change Time (T-T/C-C):2.2 Sec. /4.4 Sec.
- Rapid Feed (X, Y, Z):1,969ipm (50m/min) X/Y x 1,417ipm (36m/min) Z
- Power Requirement:30KVA
Features
- Enhanced control capability with Kitamura’s feature packed Arumatik-Mi control
- Ideal for heavy duty cutting of molds to the high-speed accuracy cutting for high precision parts
- Positioning Accuracy: ±0.000078” Full Stroke, Repeatability: ±0.000039”
- Rigid Meehanite cast iron construction with solid box ways (X & Y Axes)
- High Torque 20HP AC, 20,000rpm 4-step gear driven, dual contact spindle
- Plumbed and ready for coolant thru the spindle – can be added in field
- 2,800 block/sec processing speeds for smoother and faster machining of complex work pieces
- Flexibility with the ability to add 4th/5th axis in the field
Mycenter-4XG#40
Specifications
- Table Size:20.6” x 43.3” (522 x 1,100mm)
- Travel (X, Y, Z):40” x 20” x 20”(1,016 x 510 x 510mm)
- Spindle Taper:NST No. 40
- Spindle Speed:20~20,000rpm – Gear Drive, 4-Step
- Tool Storage Capacity:40 Pcs. (60 Opt.)
- Tool Change Time (T-T/C-C):1.2 Sec. /4.7 Sec.
- Rapid Feed (X, Y x Z):1,969ipm (50m/min) x 1,417ipm (36m/min)
- Power Requirement:35KVA
Features
- Ideal for machining larger size parts and molds
- Positioning Accuracy: ±0.000078” Full Stroke, Repeatability: ±0.000039”
- Rigid Meehanite cast iron construction with in-house induction hardened solid box ways
- Choice of #40 or #50 taper spindles for maximum machining flexibility
- Standard 40-Tool ATC with 60 tools as available options
- Flexibility with the ability to add 4th/5th axis in the field
- Available with a 2-APC, high efficiency, factory installed shuttle style pallet system as an Option
Mycenter-4XG#50
Specifications
- Table Size:20.6” x 43.3” (522 x 1,100mm)
- Travel (X, Y, Z):40” x 20” x 20”(1,016 x 510 x 510mm)
- Spindle Taper:NST No. 50
- Spindle Speed:20~10,000rpm – Gear Drive, 4-Step
- Tool Storage Capacity:40 Pcs. (60 Opt.)
- Tool Change Time (T-T/C-C):2.5 Sec. /8.0 Sec.
- Rapid Feed (X, Y, Z):1,969ipm (50m/min) x 1,417ipm (36m/min)
- Power Requirement:35KVA
Features
- Ideal for machining larger size parts and molds
- Positioning Accuracy: ±0.000078” Full Stroke, Repeatability: ±0.000039”
- Rigid Meehanite cast iron construction with in-house induction hardened solid box ways
- Choice of #40 or #50 taper spindles for maximum machining flexibility
- Standard 40-Tool ATC with 60 tools as available options
- Flexibility with the ability to add 4th/5th axis in the field
- Available with a 2-APC, high efficiency, factory installed shuttle style pallet system as an Option
Mycenter-7X#40
Specifications
- Table Size:25.6” x 66.9” (650 x 1,700mm)
- Travel (X, Y, Z):60.2” x 25.6” x 27.0”(1,530 x 650 x 686mm)
- Spindle Taper:NST No. 40, NST No. 50
- Spindle Speed:20~10,000rpm (40~15,000rpm Opt.) – Gear Drive, 4-Step
- Tool Storage Capacity:30 Pcs. (40, 60 Opt.)
- Tool Change Time (T-T/C-C):2.0 Sec. /6.5 Sec.
- Rapid Feed (X, Y x Z):945ipm (24m/min) x 787.4ipm (20m/min)
- Power Requirement:40KVA
Features
- Ideal for machining larger size parts and molds
- Positioning Accuracy: ±0.000078” Full Stroke, Repeatability: ±0.000039”
- Rigid Meehanite cast iron construction with solid box ways
- Choice of #40 or #50 taper spindles for maximum machining flexibility
- Standard 30-Tool ATC with 40 or 60 tools as available options
- Flexibility with the ability to add 4th/5th axis in the field
- Powerful geared spindles delivery high torque and high speeds for maximum machining flexibility
Mycenter-7X#50
Specifications
- Table Size:25.6” x 66.9” (650 x 1,700mm)
- Travel (X, Y, Z):60.2” x 25.6” x 27.0”(1,530 x 650 x 686mm)
- Spindle Taper:NST No. 50
- Spindle Speed:50~5,000rpm (20~10,000rpm Opt.) – Gear Drive
- Tool Storage Capacity:30 Pcs. (40, 60 Opt.)
- Tool Change Time (T-T/C-C):2.5 Sec. /8.5 Sec.
- Rapid Feed (X, Y x Z):945ipm (24m/min) x 787.4ipm (20m/min)
- Power Requirement:40KVA
Features
- Ideal for machining larger size parts and molds
- Positioning Accuracy: ±0.000078” Full Stroke, Repeatability: ±0.000039”
- Rigid Meehanite cast iron construction with solid box ways
- Choice of #40 or #50 taper spindles for maximum machining flexibility
- Standard 30-Tool ATC with 40 or 60 tools as available options
- Flexibility with the ability to add 4th/5th axis in the field
- Powerful geared spindles delivery high torque and high speeds for maximum machining flexibility
Mycenter-2XD "Sparkchanger"
Specifications
- Table Size:15.7” x 22.0” (400 x 560mm)
- Travel (X, Y, Z):23.6” x 20.1” x 20.1”(600 x 510 x 510mm)
- Spindle Taper:NST No. 40
- Spindle Speed:12,000rpm, NRG Belt Drive
- Tool Storage Capacity:40 Pcs.
- Tool Change Time (T-T/C-C):2.8 Sec. /5.2 Sec.
- Rapid Feed (X, Y x Z):1,889ipm (48m/min) X/Y x 1,654ipm (42m/min) Z
- Power Requirement:30KVA
Features
- Ideal for machining small to medium sized work pieces
- Standard 2-station, factory installed 180 degree rotating APC. Uniquely compact design
- Heavily ribbed stiff cast Meehanite C-Frame construction
- #40, 35HP, 12,000rpm NRG belt driven spindle offers power that exceeds industry standards
- Convenient and flexible standard scraper type chip conveyor
- Operator friendly Kitamura Arumatik-Jr. CNC Controller offers up to 16x faster processing speeds!
Mycenter-3XD
Specifications
- Table Size:19.7” x 33.9” (500 x 860mm)
- Travel (X, Y, Z):30” x 20.1” x 20.1”(760 x 510 x 510mm)
- Spindle Taper:NST No. 40
- Spindle Speed:12,000rpm, NRG Belt Drive
- Tool Storage Capacity:24 Pcs.
- Tool Change Time (T-T/C-C):2.3 Sec. /6.0 Sec.
- Rapid Feed (X, Y x Z):1,889ipm (48m/min) X/Y x 1,654ipm (42m/min) Z
- Power Requirement:25KVA
Features
- Ideal for machining small to medium sized work pieces
- Large work envelope within a uniquely compact design
- Heavily ribbed stiff cast Meehanite C-Frame construction
- #40, 35HP, 12,000rpm NRG belt driven spindle offers power that exceeds industry standards
- Standard scraper type chip conveyor can be installed on either the right or left-hand side of the machine
- Operator friendly Kitamura Arumatik-Jr. CNC Controller offers up to 16x faster processing speeds!
Mycenter-4XV
Specifications
- Table Size:19.7” x 44.1” (500 x 1,120mm)
- Travel (X, Y, Z):40.2” x 20.1” x 20.1”(1,020 x 510 x 510mm)
- Spindle Taper:NST No. 40
- Spindle Speed:15,000rpm, Built-In
- Tool Storage Capacity:40 Pcs.
- Tool Change Time (T-T/C-C):2.2 Sec. /4.2 Sec.
- Rapid Feed (X, Y x Z):2,047ipm (52m/min) X/Y x 1,890ipm (48m/min) Z
- Power Requirement:30KVA
Features
- 40 Tool Standard ATC
- Large work envelope within a uniquely compact design
- Heavily ribbed stiff cast Meehanite C-Frame construction
- #40, 41HP, high speed 15,000rpm built in spindle offers high speeds and heavy duty cutting capabilities
- Standard scraper type chip conveyor can be installed on either the right or left-hand side of the machine
- Operator friendly Kitamura Arumatik-Jr. CNC Controller offers up to 16x faster processing speeds!
