The FMB Minimag 20 is a reliable and high-performance automatic bar loading magazine feeder engineered to maximize the efficiency of Swiss-type CNC lathes. This unit is capable of processing small-diameter bar material ranging from 2 mm to 20 mm (0.078 inch to 0.787 inch) and supports bar lengths up to 12 feet 5 inches (3-800 mm). It features an integrated Swiss headstock synchronization device, which ensures flawless compatibility with fast-moving sliding headstock lathes, simplifying complex operations like peck drilling and threading on small bars.

Productivity is enhanced by the machine’s design for quick changeover. The patented polyurethane guide channel system dampens noise and vibration, and an entire channel set can be fully changed in approximately 10 minutes, or in 3 minutes if staying within the same channel set range. The machine also utilizes a self-centering mechanical gripper for both inserting new bar stock and extracting the remnant, which automatically handles the process without requiring manual adjustment for different bar sizes. The control system is user-friendly, featuring Omron motion control and a touch screen for easy parameter changes. The Minimag 20 ensures material support and minimal friction via its hydrodynamic support system utilizing high-volume oil flow, making it a smart choice for continuous, high-tolerance machining.
