The LS-1000 L10 is a premier model within the JTEKT Takisawa LS Series, known for its large capacity and superduty construction. As a 2-axis plus C-axis Horizontal Turning Center, it is engineered for high-torque, high-speed turning of large and heavy workpieces. The foundation of its strength lies in its extra heavy-duty design featuring Box Guideways, which provide exceptional rigidity and dampening capacity crucial for maintaining accuracy and extending tool life during heavy cutting.

The spindle system is designed for power and precision, featuring a fine-ground precision gearbox that delivers high cutting torque and enables superior surface finishes. It boasts a maximum workpiece swing of 40.1 inches (1,020 mm), a maximum turning diameter of 35.4 inches (900 mm), and a maximum turning length of 40.6 inches (1,031 mm), accommodating substantial components. The spindle is driven by a robust motor providing 50 HP (37 kW) for 30 minutes (40 HP continuous) and a top speed of 1,200 RPM. With a 7.1-inch (180 mm) bar work capacity and a 20-inch chuck size, the LS-1000 L10 is a definitive value solution for maximizing production and flexibility across challenging materials, including high-temp alloys like Titanium and Stainless Steel.
