The NEX-110 is a key model in the JTEKT Takisawa NEX Series- offering a robust and flexible solution for high-torque turning and milling requirements. The machine’s core strength lies in its high-torque gearbox spindle, making it exceptionally well-suited for tough materials like ferrous metals, high-temp alloys, and stainless steel. The standard machine is a 2-axis turning center built with linear guideway technology to ensure speed and accuracy.

Its generous work envelope allows for a 19.4-inch max swing, a 15.7-inch max turning diameter, and a 25.8-inch max turning length, accommodating a 3-inch max bar work capacity. The 10-inch chuck machine is powered by a 25 HP ( 18.5 kW ) spindle drive motor and achieves speeds up to 3,500 RPM. To maximize production flexibility and part complexity, the NEX-110 is available in two advanced variants: the NEX-110M for turning with milling capabilities, and the NEX-110Y, which includes both milling and a powerful Y-axis for off-center machining. This versatility makes the NEX-110 an exceptional value for shops requiring both power and multi-tasking options.
