The WHT 110-130 series from TOS VARNSDORF represents a new generation of Horizontal Machining Centers designed for unparalleled flexibility and precision in the machining of diverse, complex components. This machine’s foundation is a highly rigid and stable design, utilizing a modular construction kit that allows it to be precisely configured to meet specific customer requirements. It excels in coordinate drilling, boring, milling, and thread cutting on challenging box-type and plate workpieces.

Key to its performance is a powerful work spindle, available in diameters of 110 mm (WHT 110) or 130 mm (WHT 130), featuring a 50 ISO clamping taper and a robust 37 kW drive. The spindle offers a speed range up to 3000 rpm. This versatility is further enhanced by generous axis travels: X-axis (table transversal) up to 3000 mm, Y-axis (headstock vertical) up to 2000 mm, and Z-axis (column longitudinal) up to 1700 mm. The machine is also equipped with a B-axis rotary table for multi-sided machining. For automated production, the WHT 110-130 can be seamlessly integrated with optional equipment like Automatic Tool Changers (ATC) with capacities up to 60 or 80 tools, and Automatic Pallet Change (APC) systems for continuous, unmanned operation. This makes the WHT 110-130 an ideal solution for modern manufacturing demanding high performance, precision, and automation from a single machine.
