The W100A is a distinguished Conventional Horizontal Boring Mill from TOS VARNSDORF, representing the pinnacle of their traditional, robust machining technology. This table type machine is built with a solid design that guarantees longevity and precision in demanding industrial environments. It features a large 100 mm workspindle diameter and accepts a 50 ISO clamping taper. The machine’s performance is driven by a spindle speed range up to 1120 rpm.

Designed for heavy-duty, versatile boring operations, the W100A offers generous travel capacities, including 1600 mm in the X axis (table transversal), 1120 mm in the Y axis (headstock), and an extensive 900 mm spindle stroke (W). The table clamping surface can accommodate parts up to 1500 mm x 1500 mm and supports a substantial maximum loading capacity of 3000 kg. With its straightforward operation and superior build quality, the W100A remains the last conventional machine standardly produced by the company, serving as a reliable cornerstone for shops that require classic horizontal boring capabilities.

MAIN PARAMETERS
