The Fryer TC-160H is a high-capacity model in the TC-H Series of Horizontal Traveling Column Machining Centers, specifically engineered to handle the stable and precise machining of very long and heavy components. The machine’s design maximizes the work envelope while maintaining rigidity with a fixed table.

Key Specifications

• Traveling Column Design: Features a fixed table with high load capacity, while the column travels along the X-axis to provide exceptional length capacity.
• Travel (X/Y/Z): 160” x 24” (36” optional) x 24” (32” optional)
• Table Size: 160” x 24”
• Maximum Table Load: Over 10,000 lbs.
• Spindle: Rugged 40 taper (50 taper optional) horizontal spindle.
• Power: High-torque 30 HP spindle motor delivering 155 ft/lbs of torque.
• Speed: Fast 1,000 IPM rapid feedrate.
• Tooling: Comes with a 24 or 40 tool Automatic Tool Changer (ATC).

Features & Benefits

The TC-160H is built for heavy-duty, long-part manufacturing, offering an expansive 160-inch X-axis travel. The fixed table design guarantees exceptional stability for workpieces weighing over 10,000 lbs, making fixturing easier. Control is provided by the user-friendly Fryer / Siemens 828-HS CNC control, featuring Simple Menu Programming and fast set-up keys to boost efficiency in producing large, specialized parts.
